EAN: 4711213680021
Main Features
Power-Saving, High Performance Ethernet Networking
In line with the energy-saving trend worldwide, PLANET delivers the new generation Green Networking Switch- FNSW-2401. The FNSW-2401 is a 48-Port 10/100Base-TX Fast Ethernet Switch upgraded from earlier version and brings both benefits of energy saving and high performance. It is specially designed for SOHO, SMB and Workgroup users. The FNSW-2401 uses new engine that provides power saving up to 22% less energy but maintains high performance efficiently.
Energy Saving
The FNSW-2401 incorporates advanced Green Networking technology:
High Performance
The high performance throughput (filtering / forwarding rate: 14,880 packets per second in 10Mbps, 148,800pps in 100Mbps) and dynamic shared memory buffer help the FNSW-2401 boost bandwidth, eliminate unnecessary traffic, and relieve congestion on your critical server path. It also supports IEEE 802.1p Class of Service (CoS) features to improve network utilization more efficiently. The FNSW-2401 is the ideal choice to alleviate bottlenecks in client / server and peer-to-peer environments in a cost effective way.
Plug and Play
The FNSW-2401 provides users with high speed network connections. With its Auto-Negotiation capability, all the RJ-45/STP ports of the FNSW-2401 can be configured to speeds of 10/20Mbps or 100/200Mbps automatically. What's more is the MDI/ MDIX auto-detection for easy, plug and play connection, regardless of
the cabling type, straight through or crossover.
Application
Backbone Switch With up to 4.8Gbps switching fabric, the FNSW-2401 can provide high bandwidth Fast Ethernet network workgroup and connect workstations and other network devices quickly and easily
Department Switch
Uplink directly by any straight or crossover cable to the backbone switch, the FNSW-2401 provides the connectivity to back plane yet segment the network traffic of the department to your backbone.
Application
Department / Workgroup PoE Switch:
Providing up to 8 PoE, in-line power interface, the FNSW-1608PS can easily build a power central-controlled IP phone system, IP Camera system, AP group for the enterprise. For instance, 8 camera / AP can be easily installed around the corner in the company for surveillance demands or build a wireless roaming environment in the office.
Without the power-socket limitation, the FNSW-1608PS makes the installation of cameras or WLAN AP more easily and efficiently
Hardware Specification
10/100Base-TX Ports
24-port
Switch Processing Scheme
Store and Forward
Switch Fabric
4.8Gbps
Switch Throughput
3.57Mbps
Shared Buffer
1.25Mbps
Mac Address Table
8k entries
Flow Control
Back pressure for half duplex mode, IEEE 802.3x Pause Frame for full duplex mode
Power Green Ethernet
Supports from10m to 100m in length. Power saving up to 12%
Standards Conformance
Standards Conformance
IEEE 802.3 (Ethernet)
IEEE 802.3u (Fast Ethernet)
IEEE 802.3x (Full-duplex flow control)
IEEE 802.1p (Class of Service)
