EAN: 4043619805365
This M12 sensor cable by Delock can be used for direct current applications. The L-coded version has 5 power contacts with a rated current of 16 A at 63 V with which currents can be reliably transmitted. This can be used to supply power to fieldbus components, power supply units, industrial machines and motors, for e.g., where a high current and low voltage are required.
Specification• Connectors:
1 x M12 male 5 pin L-coded
1 x M12 male 5 pin L-coded
• Copper conductor
• Shielded
• Cable gauge: 14 AWG (2.5 mm²)
• Rated current: 16 A / 63 V
• Spanner width: SW13
• Cable diameter: ca. 10.4 mm
• Cable jacket material: PUR
• Suitable for drag chains
• Drag chain speed: up to max. 5 m/s
• Tightening torque: 0.6 Nm
• Bending radius (fixed): 5 x outer diameter
• Bending radius (movable): 10 x outer diameter
• Max. number of bending cycles: 5,000,000
• Max. number of torsion cycles: 500,000
• Torsional stress: ± 180 °/m
• Operating temperature (fixed): -40 °C ~ 80 °C
• Operating temperature (movable): -25 °C ~ 75 °C
• Flammability class: UL94HB
• Halogen-free, silicone-free, oil-resistant
• Protection class: IP66 / IP67
• Material thread: zinc diecast
• Colour: grey
• Length incl. connectors: ca. 5 m
• M12 cable
Ook bij Amazon
Vergelijk de prijs op Amazon.nl
We mailen je binnen 24 uur een antwoord over de Delock M12 Cable L-coded 5 pin male to male PUR suitable for drag chains 5 m grey. Geen verkooppraat.
This M12 sensor cable by Delock can be used for direct current applications. The L-coded version has 5 power contacts with a rated current of 16 A at 63 V with which currents can be reliably transmitted. This can be used to supply power to fieldbus components, power supply units, industrial machines and motors, for e.g., where a high current and low voltage are required.
Specification• Connectors:
1 x M12 male 5 pin L-coded
1 x M12 male 5 pin L-coded
• Copper conductor
• Shielded
• Cable gauge: 14 AWG (2.5 mm²)
• Rated current: 16 A / 63 V
• Spanner width: SW13
• Cable diameter: ca. 10.4 mm
• Cable jacket material: PUR
• Suitable for drag chains
• Drag chain speed: up to max. 5 m/s
• Tightening torque: 0.6 Nm
• Bending radius (fixed): 5 x outer diameter
• Bending radius (movable): 10 x outer diameter
• Max. number of bending cycles: 5,000,000
• Max. number of torsion cycles: 500,000
• Torsional stress: ± 180 °/m
• Operating temperature (fixed): -40 °C ~ 80 °C
• Operating temperature (movable): -25 °C ~ 75 °C
• Flammability class: UL94HB
• Halogen-free, silicone-free, oil-resistant
• Protection class: IP66 / IP67
• Material thread: zinc diecast
• Colour: grey
• Length incl. connectors: ca. 5 m
• M12 cable
De Delock M12 Cable L-coded 5 pin male to male PUR suitable for drag chains 5 m grey is een product van Delock. Op deze pagina vind je de volledige productinformatie, actuele prijzen en reviews.
De Delock M12 Cable L-coded 5 pin male to male PUR suitable for drag chains 5 m grey is momenteel verkrijgbaar vanaf € 191,98 bij Bol.com. Prijzen kunnen dagelijks wisselen.
De Delock M12 Cable L-coded 5 pin male to male PUR suitable for drag chains 5 m grey heeft (nog) geen eigen reviewscore. Op Productvraag staat gemiddeld een waardering van 4,85/5 op basis van 1178 reviews van bezoekers.
De Delock M12 Cable L-coded 5 pin male to male PUR suitable for drag chains 5 m grey is verkrijgbaar bij Bol.com. Klik op een aanbieder om direct naar de productpagina te gaan.
De prijzen worden dagelijks automatisch ververst vanuit onze partnerwebshops. De definitieve prijs inclusief eventuele acties zie je op de webshop zelf.
Productvraag verzamelt productinformatie, prijzen en reviews van Nederlandse webshops op één plek. Zo kun je snel zien wat een product kost, wat gebruikers ervan vinden en waar je het kunt kopen.
